Nagata Microtia and Reconstructive Plastic Surgery Clinic
Satoru Nagata, M.D., Ph.D. 31/July/2020
1st-stage operation for atypical concha type microtia complicated with low hairline and fistula
永田小耳症形成外科クリニック・永田 悟・2020年7月31日
耳前瘻孔とローヘアーラインを伴う非定形耳甲介型小耳症の肋軟骨移植術

Preoperative appearance
of atypical concha type microtia
complicated with low hairline and fistula.
耳前瘻孔とローヘアーラインを伴う
非定形耳甲介型小耳症の術前。

Determine the proper anatomical location
with transparent film template.
透明フイルムに印刷した本人サイズの設計図を用いて
耳介の正常な場所と大きさを決定する。

The outline for the 1st-stage operation.
肋軟骨移植術の手術デザイン。

Fabricated 3-dimensional costal cartilage frame
[3-D frame] and paper template.
作成した3次元肋軟骨フレームと紙型。

The temporoparietal fascia flap
[TPF] is elevated.
Skin flaps formed,
anterior skin flap.
Fistula excised.
Ultra-delicate split thickness scalp skin
[UDSTS] is harvested.
Hair follicle portion excised.
TPFを挙上した。
耳垂前面皮弁を作成した。
耳前瘻孔を摘出した。
頭皮分層皮膚を採取した。
毛根部を切除した。

3-D fame is grafted
in its proper anatomical location
and lower portion is covered with
anterior skin flap of the lobule.
3次元肋軟骨フレームを解剖学的に正しい位置へ移植して
下方を耳垂前面皮弁で被覆した。

Upper portion of 3-D frame is covered with TPF.
3次元肋軟骨フレームの上方をTPFで被覆した。

TPF portion is covered with UDSTS.
TPFの上に頭皮分層皮膚を移植した。

At the end of the 1st-stage operation
with Bolster fixation sutures.
ボルスター縫合固定を行って手術終了。
このブログの写真は小耳症治療をご理解いただくために、参考資料として掲載させていただいています。それぞれの症状によって、手術結果は異なりますのでご了承ください。
小耳症手術による合併症
一過性の顔面神経麻痺 浅側頭動・静脈の血行不良による植皮の生着不良 感染 移植軟骨の露出 気胸 術後肺炎 縫合不全 ハゲ 床ずれ その他
上記のような合併症が生じた場合は、症状に応じて対処致します。場合によっては再手術を行う可能性もあります。
Satoru Nagata, M.D., Ph.D. 31/July/2020
1st-stage operation for atypical concha type microtia complicated with low hairline and fistula
永田小耳症形成外科クリニック・永田 悟・2020年7月31日
耳前瘻孔とローヘアーラインを伴う非定形耳甲介型小耳症の肋軟骨移植術

Preoperative appearance
of atypical concha type microtia
complicated with low hairline and fistula.
耳前瘻孔とローヘアーラインを伴う
非定形耳甲介型小耳症の術前。

Determine the proper anatomical location
with transparent film template.
透明フイルムに印刷した本人サイズの設計図を用いて
耳介の正常な場所と大きさを決定する。

The outline for the 1st-stage operation.
肋軟骨移植術の手術デザイン。

Fabricated 3-dimensional costal cartilage frame
[3-D frame] and paper template.
作成した3次元肋軟骨フレームと紙型。

The temporoparietal fascia flap
[TPF] is elevated.
Skin flaps formed,
anterior skin flap.
Fistula excised.
Ultra-delicate split thickness scalp skin
[UDSTS] is harvested.
Hair follicle portion excised.
TPFを挙上した。
耳垂前面皮弁を作成した。
耳前瘻孔を摘出した。
頭皮分層皮膚を採取した。
毛根部を切除した。

3-D fame is grafted
in its proper anatomical location
and lower portion is covered with
anterior skin flap of the lobule.
3次元肋軟骨フレームを解剖学的に正しい位置へ移植して
下方を耳垂前面皮弁で被覆した。

Upper portion of 3-D frame is covered with TPF.
3次元肋軟骨フレームの上方をTPFで被覆した。

TPF portion is covered with UDSTS.
TPFの上に頭皮分層皮膚を移植した。

At the end of the 1st-stage operation
with Bolster fixation sutures.
ボルスター縫合固定を行って手術終了。
このブログの写真は小耳症治療をご理解いただくために、参考資料として掲載させていただいています。それぞれの症状によって、手術結果は異なりますのでご了承ください。
小耳症手術による合併症
一過性の顔面神経麻痺 浅側頭動・静脈の血行不良による植皮の生着不良 感染 移植軟骨の露出 気胸 術後肺炎 縫合不全 ハゲ 床ずれ その他
上記のような合併症が生じた場合は、症状に応じて対処致します。場合によっては再手術を行う可能性もあります。
Nagata Microtia and Reconstructive Plastic Surgery Clinic
Satoru Nagata, M.D., Ph.D. 30/July/2020
1st-stage operation for concha type microtia
永田小耳症形成外科クリニック・永田 悟・2020年7月30日
耳甲介型小耳症の肋軟骨移植術

Preoperative appearance
of concha type microtia.
耳甲介型小耳症の術前。

Determine the proper anatomical location
with transparent film template.
透明フイルムに印刷した本人サイズの設計図を
用いて耳介の正常な場所と大きさを決定する。

The outline for the 1st-stage operation.
肋軟骨移植術の手術デザイン。

Fabricated 3-dimensional costal cartilage frame
[3-D frame] and paper template.
作成した3次元肋軟骨フレームと紙型。

Skin flaps formed,
anterior skin flap of the lobule,
posterior skin flap of the lobule,
mastoid skin flap.
Almost remnant ear cartilage removed,
except tragus, incisula-intertragica and anti-tragus.
Skin pocket created.
皮弁形成を行った。
耳垂前面皮弁、
耳垂後面皮弁、
乳突洞部皮弁。
耳珠、珠間切痕、対珠を除く
ほとんどの遺残耳介軟骨を摘出した。

3-D frame is grafted
under the skin pocket
and reconstructed auricle.
3次元肋軟骨フレームを皮下ポケットへ移植して再建した耳介。

At the end of the 1st-stage operation
with Bolster fixation sutures.
ボルスター縫合固定を行って手術終了。
このブログの写真は小耳症治療をご理解いただくために、参考資料として掲載させていただいています。それぞれの症状によって、手術結果は異なりますのでご了承ください。
小耳症手術による合併症
一過性の顔面神経麻痺 浅側頭動・静脈の血行不良による植皮の生着不良 感染 移植軟骨の露出 気胸 術後肺炎 縫合不全 ハゲ 床ずれ その他
上記のような合併症が生じた場合は、症状に応じて対処致します。場合によっては再手術を行う可能性もあります。
Satoru Nagata, M.D., Ph.D. 30/July/2020
1st-stage operation for concha type microtia
永田小耳症形成外科クリニック・永田 悟・2020年7月30日
耳甲介型小耳症の肋軟骨移植術

Preoperative appearance
of concha type microtia.
耳甲介型小耳症の術前。

Determine the proper anatomical location
with transparent film template.
透明フイルムに印刷した本人サイズの設計図を
用いて耳介の正常な場所と大きさを決定する。

The outline for the 1st-stage operation.
肋軟骨移植術の手術デザイン。

Fabricated 3-dimensional costal cartilage frame
[3-D frame] and paper template.
作成した3次元肋軟骨フレームと紙型。

Skin flaps formed,
anterior skin flap of the lobule,
posterior skin flap of the lobule,
mastoid skin flap.
Almost remnant ear cartilage removed,
except tragus, incisula-intertragica and anti-tragus.
Skin pocket created.
皮弁形成を行った。
耳垂前面皮弁、
耳垂後面皮弁、
乳突洞部皮弁。
耳珠、珠間切痕、対珠を除く
ほとんどの遺残耳介軟骨を摘出した。

3-D frame is grafted
under the skin pocket
and reconstructed auricle.
3次元肋軟骨フレームを皮下ポケットへ移植して再建した耳介。

At the end of the 1st-stage operation
with Bolster fixation sutures.
ボルスター縫合固定を行って手術終了。
このブログの写真は小耳症治療をご理解いただくために、参考資料として掲載させていただいています。それぞれの症状によって、手術結果は異なりますのでご了承ください。
小耳症手術による合併症
一過性の顔面神経麻痺 浅側頭動・静脈の血行不良による植皮の生着不良 感染 移植軟骨の露出 気胸 術後肺炎 縫合不全 ハゲ 床ずれ その他
上記のような合併症が生じた場合は、症状に応じて対処致します。場合によっては再手術を行う可能性もあります。
Nagata Microtia and Reconstructive Plastic Surgery Clinic
Satoru Nagata, M.D., Ph.D. 28/July/2020
1st-stage operation for lobule type microtia
永田小耳症形成外科クリニック・永田 悟・2020年7月28日
耳垂残存型小耳症の肋軟骨移植術

Preoperative appearance
of lobule type microtia.
耳垂残存型小耳症の術前。

Determine the proper anatomical location
with transparent film template.
透明フイルムに印刷した本人サイズの設計図を用いて
耳介の正常な場所と大きさを決定する。

The outline for the 1st-stage operation.
肋軟骨移植術の手術デザイン。

Fabricated 3-dimensional costal cartilage frame
[3-D frame] and paper template.
作成した3次元肋軟骨フレームと紙型。

Skin flaps formed,
anterior skin flap of the lobule,
posterior skin flap of the lobule,
mastoid skin flap,
tragus skin flap.
All remnant ear cartilage removed.
Skin pocket created.
皮弁形成を行った。
耳垂前面皮弁、
耳垂後面皮弁、
乳突洞部皮弁、
耳珠用皮弁。
すべての遺残耳介軟骨を摘出した。
皮下ポケットを作成した。

3-D frame is grafted
under the skin pocket
and reconstructed auricle.
3次元肋軟骨フレームを
皮下ポケットへ移植して
再建した耳介。

At the end of the 1st-stage operation
with Bolster fixation sutures.
ボルスター縫合固定を行って手術終了。
このブログの写真は小耳症治療をご理解いただくために、参考資料として掲載させていただいています。それぞれの症状によって、手術結果は異なりますのでご了承ください。
小耳症手術による合併症
一過性の顔面神経麻痺 浅側頭動・静脈の血行不良による植皮の生着不良 感染 移植軟骨の露出 気胸 術後肺炎 縫合不全 ハゲ 床ずれ その他
上記のような合併症が生じた場合は、症状に応じて対処致します。場合によっては再手術を行う可能性もあります。
Satoru Nagata, M.D., Ph.D. 28/July/2020
1st-stage operation for lobule type microtia
永田小耳症形成外科クリニック・永田 悟・2020年7月28日
耳垂残存型小耳症の肋軟骨移植術

Preoperative appearance
of lobule type microtia.
耳垂残存型小耳症の術前。

Determine the proper anatomical location
with transparent film template.
透明フイルムに印刷した本人サイズの設計図を用いて
耳介の正常な場所と大きさを決定する。

The outline for the 1st-stage operation.
肋軟骨移植術の手術デザイン。

Fabricated 3-dimensional costal cartilage frame
[3-D frame] and paper template.
作成した3次元肋軟骨フレームと紙型。

Skin flaps formed,
anterior skin flap of the lobule,
posterior skin flap of the lobule,
mastoid skin flap,
tragus skin flap.
All remnant ear cartilage removed.
Skin pocket created.
皮弁形成を行った。
耳垂前面皮弁、
耳垂後面皮弁、
乳突洞部皮弁、
耳珠用皮弁。
すべての遺残耳介軟骨を摘出した。
皮下ポケットを作成した。

3-D frame is grafted
under the skin pocket
and reconstructed auricle.
3次元肋軟骨フレームを
皮下ポケットへ移植して
再建した耳介。

At the end of the 1st-stage operation
with Bolster fixation sutures.
ボルスター縫合固定を行って手術終了。
このブログの写真は小耳症治療をご理解いただくために、参考資料として掲載させていただいています。それぞれの症状によって、手術結果は異なりますのでご了承ください。
小耳症手術による合併症
一過性の顔面神経麻痺 浅側頭動・静脈の血行不良による植皮の生着不良 感染 移植軟骨の露出 気胸 術後肺炎 縫合不全 ハゲ 床ずれ その他
上記のような合併症が生じた場合は、症状に応じて対処致します。場合によっては再手術を行う可能性もあります。
Nagata Microtia and Reconstructive Plastic Surgery Clinic
Satoru Nagata, M.D., Ph.D. 21/July/2020
1st-stage operation for atypical concha type microtia
永田小耳症形成外科クリニック・永田 悟・2020年7月21日
非定形耳甲介型小耳症の肋軟骨移植術

Determine the proper anatomical location
with transparent film template.
透明フイルムに印刷した本人サイズの設計図を用いて
耳介の正常な場所と大きさを決定する。

Preoperative appearance
of atypical concha type microtia.
The outline for the 1st-stage operation.
非定形耳甲介型小耳症の術前。
肋軟骨移植術の手術デザイン。

Fabricated 3-dimensional costal cartilage frame
[3-D frame] and paper template.
作成した3次元肋軟骨フレームと紙型。

Skin flaps formed,
anterior skin flap of the lobule,
posterior skin flap of the lobule,
mastoid skin flap.
Almost remnant ear cartilage removed,
except anti-tragus, incisula inter-tragica, and tragus.
Skin pocket created.
皮弁形成を行った。
耳垂前面皮弁、
耳垂後面皮弁、
乳突洞部皮弁。
耳珠、珠間切痕、対珠を除く大部分の遺残耳介軟骨を摘出した。
皮下ポケットを作成した。

3-D frame is grafted
under the skin pocket
and reconstructed auricle.
3次元肋軟骨フレームを皮下ポケットへ
移植して再建した耳介。

At the end of the 1st-stage operation
with Bolster fixation sutures.
ボルスター縫合固定を行って手術終了。
このブログの写真は小耳症治療をご理解いただくために、参考資料として掲載させていただいています。それぞれの症状によって、手術結果は異なりますのでご了承ください。
小耳症手術による合併症
一過性の顔面神経麻痺 浅側頭動・静脈の血行不良による植皮の生着不良 感染 移植軟骨の露出 気胸 術後肺炎 縫合不全 ハゲ 床ずれ その他
上記のような合併症が生じた場合は、症状に応じて対処致します。場合によっては再手術を行う可能性もあります。
Satoru Nagata, M.D., Ph.D. 21/July/2020
1st-stage operation for atypical concha type microtia
永田小耳症形成外科クリニック・永田 悟・2020年7月21日
非定形耳甲介型小耳症の肋軟骨移植術

Determine the proper anatomical location
with transparent film template.
透明フイルムに印刷した本人サイズの設計図を用いて
耳介の正常な場所と大きさを決定する。

Preoperative appearance
of atypical concha type microtia.
The outline for the 1st-stage operation.
非定形耳甲介型小耳症の術前。
肋軟骨移植術の手術デザイン。

Fabricated 3-dimensional costal cartilage frame
[3-D frame] and paper template.
作成した3次元肋軟骨フレームと紙型。

Skin flaps formed,
anterior skin flap of the lobule,
posterior skin flap of the lobule,
mastoid skin flap.
Almost remnant ear cartilage removed,
except anti-tragus, incisula inter-tragica, and tragus.
Skin pocket created.
皮弁形成を行った。
耳垂前面皮弁、
耳垂後面皮弁、
乳突洞部皮弁。
耳珠、珠間切痕、対珠を除く大部分の遺残耳介軟骨を摘出した。
皮下ポケットを作成した。

3-D frame is grafted
under the skin pocket
and reconstructed auricle.
3次元肋軟骨フレームを皮下ポケットへ
移植して再建した耳介。

At the end of the 1st-stage operation
with Bolster fixation sutures.
ボルスター縫合固定を行って手術終了。
このブログの写真は小耳症治療をご理解いただくために、参考資料として掲載させていただいています。それぞれの症状によって、手術結果は異なりますのでご了承ください。
小耳症手術による合併症
一過性の顔面神経麻痺 浅側頭動・静脈の血行不良による植皮の生着不良 感染 移植軟骨の露出 気胸 術後肺炎 縫合不全 ハゲ 床ずれ その他
上記のような合併症が生じた場合は、症状に応じて対処致します。場合によっては再手術を行う可能性もあります。
Nagata Microtia and Reconstructive Plastic Surgery Clinic
Satoru Nagata, M.D., Ph.D. 17/July/2020
1st-stage operation for lobule type microtia
永田小耳症形成外科クリニック・永田 悟・2020年7月17日
耳垂残存型小耳症の肋軟骨移植術

Preoperative appearance
of lobule type microtia.
耳垂残存型小耳症の術前。

Determine the proper anatomical location
with transparent film template.
透明フイルムに印刷した本人サイズの設計図を用いて
耳介の正常な場所と大きさを決定する。

The outline for the 1st-stage operation.
肋軟骨移植術の手術デザイン。

Fabricated 3-dimensional costal cartilage frame
[3-D frame] and paper template.
作成した3次元肋軟骨フレームと髪型。

Skin flaps formed,
anterior skin flap of the lobule,
posterior skin flap of the lobule,
mastoid skin flap,
tragus skin flap.
All remnant ear cartilage removed.
Skin pocket created.
皮弁形成を行った。
耳垂前面皮弁、
耳垂後面皮弁、
乳突洞部皮弁、
耳珠用皮弁。
すべての遺残耳介軟骨を摘出した。
皮下ポケットを作成した。

3-D frame is grafted
under the skin pocket
and reconstructed auricle.
3次元肋軟骨フレームを
皮下ポケットへ移植して
再建した耳介。

At the end of the 1st-stage operation
with Bolster fixation sutures.
ボルスター縫合固定を行って手術終了。
このブログの写真は小耳症治療をご理解いただくために、参考資料として掲載させていただいています。それぞれの症状によって、手術結果は異なりますのでご了承ください。
小耳症手術による合併症
一過性の顔面神経麻痺 浅側頭動・静脈の血行不良による植皮の生着不良 感染 移植軟骨の露出 気胸 術後肺炎 縫合不全 ハゲ 床ずれ その他
上記のような合併症が生じた場合は、症状に応じて対処致します。場合によっては再手術を行う可能性もあります。
Satoru Nagata, M.D., Ph.D. 17/July/2020
1st-stage operation for lobule type microtia
永田小耳症形成外科クリニック・永田 悟・2020年7月17日
耳垂残存型小耳症の肋軟骨移植術

Preoperative appearance
of lobule type microtia.
耳垂残存型小耳症の術前。

Determine the proper anatomical location
with transparent film template.
透明フイルムに印刷した本人サイズの設計図を用いて
耳介の正常な場所と大きさを決定する。

The outline for the 1st-stage operation.
肋軟骨移植術の手術デザイン。

Fabricated 3-dimensional costal cartilage frame
[3-D frame] and paper template.
作成した3次元肋軟骨フレームと髪型。

Skin flaps formed,
anterior skin flap of the lobule,
posterior skin flap of the lobule,
mastoid skin flap,
tragus skin flap.
All remnant ear cartilage removed.
Skin pocket created.
皮弁形成を行った。
耳垂前面皮弁、
耳垂後面皮弁、
乳突洞部皮弁、
耳珠用皮弁。
すべての遺残耳介軟骨を摘出した。
皮下ポケットを作成した。

3-D frame is grafted
under the skin pocket
and reconstructed auricle.
3次元肋軟骨フレームを
皮下ポケットへ移植して
再建した耳介。

At the end of the 1st-stage operation
with Bolster fixation sutures.
ボルスター縫合固定を行って手術終了。
このブログの写真は小耳症治療をご理解いただくために、参考資料として掲載させていただいています。それぞれの症状によって、手術結果は異なりますのでご了承ください。
小耳症手術による合併症
一過性の顔面神経麻痺 浅側頭動・静脈の血行不良による植皮の生着不良 感染 移植軟骨の露出 気胸 術後肺炎 縫合不全 ハゲ 床ずれ その他
上記のような合併症が生じた場合は、症状に応じて対処致します。場合によっては再手術を行う可能性もあります。
Nagata Microtia and Reconstructive Plastic Surgery Clinic
Satoru Nagata, M.D., Ph.D. 14/July/2020
1st-stage operation for lobule type microtia
永田小耳症形成外科クリニック・永田 悟・2020年7月14日
耳垂残存型小耳症の肋軟骨移植術

Preperative appearance
of lobule type microtia.
耳垂残存型小耳症の術前。

Determine the proper anatomical location
with transparent film template.
透明フイルムに印刷した
本人サイズの設計図を用いて
耳介の正常な場所と大きさを決定する。

The outline for the 1st-stage operation.
肋軟骨移植術の手術デザイン。

Fabricated 3-dimensional costal cartilage frame
[3-D frame] and paper template.
作成した3次元肋軟骨フレームと紙型。

Skin flaps formed,
anterior skin flap of the lobule,
posterior skin flap of the lobule,
mastoid skin flap,
tragus skin flap.
All remnant ear cartilage removed.
Skin pocket created.
皮弁形成を行った。
耳垂前面皮弁、
耳垂後面皮弁、
乳突洞部皮弁、
耳珠用皮弁。
すべての遺残耳介軟骨を摘出した。
皮下ポケットを作成した。

3-D frame is grafted
unde the skin pocket
and reconstructed auricle.
3次元肋軟骨フレームを
皮下ポケットへ移植して再建した耳介。

At the end of the 1st-stage operation
with Bolster fixation sutures.
ボルスター縫合固定を行って手術終了。
このブログの写真は小耳症治療をご理解いただくために、参考資料として掲載させていただいています。それぞれの症状によって、手術結果は異なりますのでご了承ください。
小耳症手術による合併症
一過性の顔面神経麻痺 浅側頭動・静脈の血行不良による植皮の生着不良 感染 移植軟骨の露出 気胸 術後肺炎 縫合不全 ハゲ 床ずれ その他
上記のような合併症が生じた場合は、症状に応じて対処致します。場合によっては再手術を行う可能性もあります。
Satoru Nagata, M.D., Ph.D. 14/July/2020
1st-stage operation for lobule type microtia
永田小耳症形成外科クリニック・永田 悟・2020年7月14日
耳垂残存型小耳症の肋軟骨移植術

Preperative appearance
of lobule type microtia.
耳垂残存型小耳症の術前。

Determine the proper anatomical location
with transparent film template.
透明フイルムに印刷した
本人サイズの設計図を用いて
耳介の正常な場所と大きさを決定する。

The outline for the 1st-stage operation.
肋軟骨移植術の手術デザイン。

Fabricated 3-dimensional costal cartilage frame
[3-D frame] and paper template.
作成した3次元肋軟骨フレームと紙型。

Skin flaps formed,
anterior skin flap of the lobule,
posterior skin flap of the lobule,
mastoid skin flap,
tragus skin flap.
All remnant ear cartilage removed.
Skin pocket created.
皮弁形成を行った。
耳垂前面皮弁、
耳垂後面皮弁、
乳突洞部皮弁、
耳珠用皮弁。
すべての遺残耳介軟骨を摘出した。
皮下ポケットを作成した。

3-D frame is grafted
unde the skin pocket
and reconstructed auricle.
3次元肋軟骨フレームを
皮下ポケットへ移植して再建した耳介。

At the end of the 1st-stage operation
with Bolster fixation sutures.
ボルスター縫合固定を行って手術終了。
このブログの写真は小耳症治療をご理解いただくために、参考資料として掲載させていただいています。それぞれの症状によって、手術結果は異なりますのでご了承ください。
小耳症手術による合併症
一過性の顔面神経麻痺 浅側頭動・静脈の血行不良による植皮の生着不良 感染 移植軟骨の露出 気胸 術後肺炎 縫合不全 ハゲ 床ずれ その他
上記のような合併症が生じた場合は、症状に応じて対処致します。場合によっては再手術を行う可能性もあります。
コロナと大雨と、どちらにしても厳しい毎日です。
皆様、お見舞い申し上げます。
さて当院では、7月4日、定例の小耳症説明会を行いました。53回目です。
マスクも消毒も、だいぶ慣れてはきましたが、暑い中のマスクは本当につらい。
でも外すわけにもいかず、なかなか悩みの種。
でも年寄りは時々はずせって?
え、年寄りって何歳から?
などどとぼけたことは言っていられない。
コロナの中、説明会に参加していただいたご家族、
ありがとうございました。
皆様、お見舞い申し上げます。
さて当院では、7月4日、定例の小耳症説明会を行いました。53回目です。
マスクも消毒も、だいぶ慣れてはきましたが、暑い中のマスクは本当につらい。
でも外すわけにもいかず、なかなか悩みの種。
でも年寄りは時々はずせって?
え、年寄りって何歳から?
などどとぼけたことは言っていられない。
コロナの中、説明会に参加していただいたご家族、
ありがとうございました。
Nagata Microtia and Reconstructive Plastic Surgery Clinic
Satoru Nagata, M.D., Ph.D. 10/July/2020
1st-stage operation for lobule type microtia
永田小耳症形成外科クリニック・永田 悟・2020年7月10日
耳垂残存型小耳症の肋軟骨移植術

Preoperative appearance
of lobule type microtia.
耳垂残存型小耳症の術前。

Determine the proper anatomical location
with transparent film template.
本人サイズの設計図を用いて
耳介の正常な場所と大きさを決定する。

The outline for the 1st-stage operation.
肋軟骨移植術の手術デザイン。

Fabricated 3-dimensional costal cartilage frame
[3-D frame] and paper template.
作成した3次元肋軟骨フレームと紙型。

Skin flaps formed,
anterior skin flap of the lobule,
posterior skin flap of the lobule,
mastoid skin flap,
tragus skin flap.
All remnant ear cartilage removed.
Skin pocket created.
皮弁形成を行った。
耳垂前面皮弁、
耳垂後面皮弁、
乳突洞部皮弁、
耳珠用皮弁。
すべての遺残耳介軟骨を摘出した。
皮下ポケットを作成した。

3-D frame is grafted
under the skin pocket
and reconstructed auricle.
3次元肋軟骨フレームを
皮下ポケットへ移植して
再建した耳介。

At the end of the 1st-stage operation
with Bolster fixation sutures.
ボルスター縫合固定を行って手術終了。
このブログの写真は小耳症治療をご理解いただくために、参考資料として掲載させていただいています。それぞれの症状によって、手術結果は異なりますのでご了承ください。
小耳症手術による合併症
一過性の顔面神経麻痺 浅側頭動・静脈の血行不良による植皮の生着不良 感染 移植軟骨の露出 気胸 術後肺炎 縫合不全 ハゲ 床ずれ その他
上記のような合併症が生じた場合は、症状に応じて対処致します。場合によっては再手術を行う可能性もあります。
Satoru Nagata, M.D., Ph.D. 10/July/2020
1st-stage operation for lobule type microtia
永田小耳症形成外科クリニック・永田 悟・2020年7月10日
耳垂残存型小耳症の肋軟骨移植術

Preoperative appearance
of lobule type microtia.
耳垂残存型小耳症の術前。

Determine the proper anatomical location
with transparent film template.
本人サイズの設計図を用いて
耳介の正常な場所と大きさを決定する。

The outline for the 1st-stage operation.
肋軟骨移植術の手術デザイン。

Fabricated 3-dimensional costal cartilage frame
[3-D frame] and paper template.
作成した3次元肋軟骨フレームと紙型。

Skin flaps formed,
anterior skin flap of the lobule,
posterior skin flap of the lobule,
mastoid skin flap,
tragus skin flap.
All remnant ear cartilage removed.
Skin pocket created.
皮弁形成を行った。
耳垂前面皮弁、
耳垂後面皮弁、
乳突洞部皮弁、
耳珠用皮弁。
すべての遺残耳介軟骨を摘出した。
皮下ポケットを作成した。

3-D frame is grafted
under the skin pocket
and reconstructed auricle.
3次元肋軟骨フレームを
皮下ポケットへ移植して
再建した耳介。

At the end of the 1st-stage operation
with Bolster fixation sutures.
ボルスター縫合固定を行って手術終了。
このブログの写真は小耳症治療をご理解いただくために、参考資料として掲載させていただいています。それぞれの症状によって、手術結果は異なりますのでご了承ください。
小耳症手術による合併症
一過性の顔面神経麻痺 浅側頭動・静脈の血行不良による植皮の生着不良 感染 移植軟骨の露出 気胸 術後肺炎 縫合不全 ハゲ 床ずれ その他
上記のような合併症が生じた場合は、症状に応じて対処致します。場合によっては再手術を行う可能性もあります。
Nagata Microtia and Reconstructive Plastic Surgery Clinic
Satoru Nagata, M.D., Ph.D. 9/July/2020
2nd-stage operation for lobule type microtia
永田小耳症形成外科クリニック・永田 悟・2020年7月9日
耳垂残存型小耳症の耳立て手術

6 months after the 1st-stage operation
for lobule type microtia and reconstructed auricle.
The outline for the 2nd-stage operation.
半年前に耳垂残存型小耳症の
肋軟骨移植を行って再建した耳介。
耳立て手術の手術デザイン。

The temporoparietal fascia flap
[TPF] is elevated.
Ultra-delicate split thickness scalp skin
[UDSTS] is harvested.
Costal cartilage block
for ear projection is fabricated.
TPFを挙上した。
頭皮分層皮膚を採取した。
耳を立てるための肋軟骨ブロックを作成した。

The reconstructed auricle is projected.
再建した耳介が立っている。

The total suture line.
縫合線の全体像。

The reconstructed auricle is projected.
再建した耳介が立っている。
このブログの写真は小耳症治療をご理解いただくために、参考資料として掲載させていただいています。それぞれの症状によって、手術結果は異なりますのでご了承ください。
小耳症手術による合併症
一過性の顔面神経麻痺 浅側頭動・静脈の血行不良による植皮の生着不良 感染 移植軟骨の露出 気胸 術後肺炎 縫合不全 ハゲ 床ずれ その他
上記のような合併症が生じた場合は、症状に応じて対処致します。場合によっては再手術を行う可能性もあります。
Satoru Nagata, M.D., Ph.D. 9/July/2020
2nd-stage operation for lobule type microtia
永田小耳症形成外科クリニック・永田 悟・2020年7月9日
耳垂残存型小耳症の耳立て手術

6 months after the 1st-stage operation
for lobule type microtia and reconstructed auricle.
The outline for the 2nd-stage operation.
半年前に耳垂残存型小耳症の
肋軟骨移植を行って再建した耳介。
耳立て手術の手術デザイン。

The temporoparietal fascia flap
[TPF] is elevated.
Ultra-delicate split thickness scalp skin
[UDSTS] is harvested.
Costal cartilage block
for ear projection is fabricated.
TPFを挙上した。
頭皮分層皮膚を採取した。
耳を立てるための肋軟骨ブロックを作成した。

The reconstructed auricle is projected.
再建した耳介が立っている。

The total suture line.
縫合線の全体像。

The reconstructed auricle is projected.
再建した耳介が立っている。
このブログの写真は小耳症治療をご理解いただくために、参考資料として掲載させていただいています。それぞれの症状によって、手術結果は異なりますのでご了承ください。
小耳症手術による合併症
一過性の顔面神経麻痺 浅側頭動・静脈の血行不良による植皮の生着不良 感染 移植軟骨の露出 気胸 術後肺炎 縫合不全 ハゲ 床ずれ その他
上記のような合併症が生じた場合は、症状に応じて対処致します。場合によっては再手術を行う可能性もあります。
Nagata Microtia and Reconstructive Plastic Surgery Clinic
Satoru Nagata, M.D., Ph.D. 7/July/2020
1st-stage operation for lobule type microtia
永田小耳症形成外科クリニック・永田 悟・2020年7月7日
耳垂残存型小耳症の肋軟骨移植術

Preoperative appearance
of lobule type microtia.
耳垂残存型小耳症の術前。

Determine the proper anatomical location
with transparent film template.
透明フイルムに印刷した本人サイズの設計図を用いて
耳介の正常な場所と大きさを決定する。

The outline for the 1st-stage operation.
肋軟骨移植術の手術デザイン。

Fabricated 3-dimensional costal cartilage frame
[3-D frame] and paper template.
作成した3次元肋軟骨フレームと紙型。

Skin flaps formed,
anterior skin flap of the lobule,
posterior skin flap of the lobule,
mastoid skin flap,
tragus skin flap.
All remnant ear cartilage removed.
Skin pocket created.
皮弁形成を行った。
耳垂前面皮弁、
耳垂後面皮弁、
乳突洞部皮弁、
耳珠用皮弁。
すべての遺残耳介軟骨を摘出した。
皮下ポケットを作成した。

3-D frame is grafted
under the skin pocket
and reconstructed auricle.
3次元肋軟骨フレームを
皮下ポケットへ移植して
再建した耳介。

At the end of the 1st-stage operation
with Bolster fixation sutures.
ボルスター縫合固定を行って手術終了。
このブログの写真は小耳症治療をご理解いただくために、参考資料として掲載させていただいています。それぞれの症状によって、手術結果は異なりますのでご了承ください。
小耳症手術による合併症
一過性の顔面神経麻痺 浅側頭動・静脈の血行不良による植皮の生着不良 感染 移植軟骨の露出 気胸 術後肺炎 縫合不全 ハゲ 床ずれ その他
上記のような合併症が生じた場合は、症状に応じて対処致します。場合によっては再手術を行う可能性もあります。
Satoru Nagata, M.D., Ph.D. 7/July/2020
1st-stage operation for lobule type microtia
永田小耳症形成外科クリニック・永田 悟・2020年7月7日
耳垂残存型小耳症の肋軟骨移植術

Preoperative appearance
of lobule type microtia.
耳垂残存型小耳症の術前。

Determine the proper anatomical location
with transparent film template.
透明フイルムに印刷した本人サイズの設計図を用いて
耳介の正常な場所と大きさを決定する。

The outline for the 1st-stage operation.
肋軟骨移植術の手術デザイン。

Fabricated 3-dimensional costal cartilage frame
[3-D frame] and paper template.
作成した3次元肋軟骨フレームと紙型。

Skin flaps formed,
anterior skin flap of the lobule,
posterior skin flap of the lobule,
mastoid skin flap,
tragus skin flap.
All remnant ear cartilage removed.
Skin pocket created.
皮弁形成を行った。
耳垂前面皮弁、
耳垂後面皮弁、
乳突洞部皮弁、
耳珠用皮弁。
すべての遺残耳介軟骨を摘出した。
皮下ポケットを作成した。

3-D frame is grafted
under the skin pocket
and reconstructed auricle.
3次元肋軟骨フレームを
皮下ポケットへ移植して
再建した耳介。

At the end of the 1st-stage operation
with Bolster fixation sutures.
ボルスター縫合固定を行って手術終了。
このブログの写真は小耳症治療をご理解いただくために、参考資料として掲載させていただいています。それぞれの症状によって、手術結果は異なりますのでご了承ください。
小耳症手術による合併症
一過性の顔面神経麻痺 浅側頭動・静脈の血行不良による植皮の生着不良 感染 移植軟骨の露出 気胸 術後肺炎 縫合不全 ハゲ 床ずれ その他
上記のような合併症が生じた場合は、症状に応じて対処致します。場合によっては再手術を行う可能性もあります。
Nagata Microtia and Reconstructive Platic Surgery Clinic
Satoru Nagata, M.D., Ph.D. 3/July/2020
1st-stage operation for lobule type microtia
永田小耳症形成外科クリニック・永田 悟・2020年7月3日
耳垂残存型小耳症の肋軟骨移植術

Preoperative appearance
of lobule type microtia.
耳垂残存型小耳症の術前。

Determine the proper anatomical location
with transparent film template.
透明フイルムに印刷した本人サイズの設計図を用いて
耳介の正常な場所と大きさを決定する。

The outline for the 1st-stage operation.
肋軟骨移植術の手術デザイン。

Fabricated 3-dimensional costal cartilage frame
[3-D frame] and paper template.
作成した3次元肋軟骨フレームと紙型。

Skin flaps formed,
anterior skin flap of the lobule,
posterior skin flap of the lobule,
mastoid skin flap,
tragus skin flap.
All remnant ear cartilage removed.
Skin pocket created.
皮弁形成を行った。
耳垂前面皮弁、
耳垂後面皮弁、
乳突洞部皮弁、
耳珠用皮弁。
すべての遺残耳介軟骨を摘出した。
皮下ポケットを作成した。

3-D frame is grafted
under the skin pocket
and reconstructed auricle.
3次元肋軟骨フレームを
皮下ポケットへ移植して
再建した耳介。

At the end of the 1st-stage operation
with Bolster fixation sutures.
ボルスター縫合固定を行って手術終了。
このブログの写真は小耳症治療をご理解いただくために、参考資料として掲載させていただいています。それぞれの症状によって、手術結果は異なりますのでご了承ください。
小耳症手術による合併症
一過性の顔面神経麻痺 浅側頭動・静脈の血行不良による植皮の生着不良 感染 移植軟骨の露出 気胸 術後肺炎 縫合不全 ハゲ 床ずれ その他
上記のような合併症が生じた場合は、症状に応じて対処致します。場合によっては再手術を行う可能性もあります。
Satoru Nagata, M.D., Ph.D. 3/July/2020
1st-stage operation for lobule type microtia
永田小耳症形成外科クリニック・永田 悟・2020年7月3日
耳垂残存型小耳症の肋軟骨移植術

Preoperative appearance
of lobule type microtia.
耳垂残存型小耳症の術前。

Determine the proper anatomical location
with transparent film template.
透明フイルムに印刷した本人サイズの設計図を用いて
耳介の正常な場所と大きさを決定する。

The outline for the 1st-stage operation.
肋軟骨移植術の手術デザイン。

Fabricated 3-dimensional costal cartilage frame
[3-D frame] and paper template.
作成した3次元肋軟骨フレームと紙型。

Skin flaps formed,
anterior skin flap of the lobule,
posterior skin flap of the lobule,
mastoid skin flap,
tragus skin flap.
All remnant ear cartilage removed.
Skin pocket created.
皮弁形成を行った。
耳垂前面皮弁、
耳垂後面皮弁、
乳突洞部皮弁、
耳珠用皮弁。
すべての遺残耳介軟骨を摘出した。
皮下ポケットを作成した。

3-D frame is grafted
under the skin pocket
and reconstructed auricle.
3次元肋軟骨フレームを
皮下ポケットへ移植して
再建した耳介。

At the end of the 1st-stage operation
with Bolster fixation sutures.
ボルスター縫合固定を行って手術終了。
このブログの写真は小耳症治療をご理解いただくために、参考資料として掲載させていただいています。それぞれの症状によって、手術結果は異なりますのでご了承ください。
小耳症手術による合併症
一過性の顔面神経麻痺 浅側頭動・静脈の血行不良による植皮の生着不良 感染 移植軟骨の露出 気胸 術後肺炎 縫合不全 ハゲ 床ずれ その他
上記のような合併症が生じた場合は、症状に応じて対処致します。場合によっては再手術を行う可能性もあります。
Nagata Microtia and Reconstructive Plastic Surgery Clinic
Satoru Nagata, M.D., Ph.D. 2/July/2020
1st-stage operation for concha type microtia
永田小耳症形成外科クリニック・永田 悟・2020年7月2日
耳甲介型小耳症の肋軟骨移植術

Preoperative appearance
of concha type microtia.
耳甲介型小耳症の術前。

Determine the proper anatomical location
with transparent film template.
本人サイズの設計図を印刷した透明フイルムを用いて、
耳介の正常な場所と大きさを設計する。

The outline for the 1st-stage operation.
肋軟骨移植術の手術デザイン。

Fabricated 3-dimensional costal cartilage frame
[3-D frame] for concha type microtia and paper template.
作成した耳甲介型小耳症に対する
3次元肋軟骨フレームと紙型。

Skin flaps formed,
anterior skin flap of the lobule,
posterior skin flap of the lobule,
mastoid skin flap.
Almost remnant ear cartilage removed
except tragus, incisula intertragica, anti-tragus.
Skin pocket created.
皮弁形成を行った。
耳垂前面皮弁、
耳垂後面皮弁、
乳突洞部皮弁。
耳珠、珠間切痕、対珠を除く大部分の遺残耳介軟骨を摘出した。
皮下ポケットを作成した。

3-D frame is grafted
under the skin pocket
and reconstructed auricle.
3次元肋軟骨フレームを
皮下ポケットへ移植して
再建した耳介。

At the end of the 1st-stage operation
with Bolster fixation sutures.
ボルスター縫合固定を行って手術終了。
このブログの写真は小耳症治療をご理解いただくために、参考資料として掲載させていただいています。それぞれの症状によって、手術結果は異なりますのでご了承ください。
小耳症手術による合併症
一過性の顔面神経麻痺 浅側頭動・静脈の血行不良による植皮の生着不良 感染 移植軟骨の露出 気胸 術後肺炎 縫合不全 ハゲ 床ずれ その他
上記のような合併症が生じた場合は、症状に応じて対処致します。場合によっては再手術を行う可能性もあります。
Satoru Nagata, M.D., Ph.D. 2/July/2020
1st-stage operation for concha type microtia
永田小耳症形成外科クリニック・永田 悟・2020年7月2日
耳甲介型小耳症の肋軟骨移植術

Preoperative appearance
of concha type microtia.
耳甲介型小耳症の術前。

Determine the proper anatomical location
with transparent film template.
本人サイズの設計図を印刷した透明フイルムを用いて、
耳介の正常な場所と大きさを設計する。

The outline for the 1st-stage operation.
肋軟骨移植術の手術デザイン。

Fabricated 3-dimensional costal cartilage frame
[3-D frame] for concha type microtia and paper template.
作成した耳甲介型小耳症に対する
3次元肋軟骨フレームと紙型。

Skin flaps formed,
anterior skin flap of the lobule,
posterior skin flap of the lobule,
mastoid skin flap.
Almost remnant ear cartilage removed
except tragus, incisula intertragica, anti-tragus.
Skin pocket created.
皮弁形成を行った。
耳垂前面皮弁、
耳垂後面皮弁、
乳突洞部皮弁。
耳珠、珠間切痕、対珠を除く大部分の遺残耳介軟骨を摘出した。
皮下ポケットを作成した。

3-D frame is grafted
under the skin pocket
and reconstructed auricle.
3次元肋軟骨フレームを
皮下ポケットへ移植して
再建した耳介。

At the end of the 1st-stage operation
with Bolster fixation sutures.
ボルスター縫合固定を行って手術終了。
このブログの写真は小耳症治療をご理解いただくために、参考資料として掲載させていただいています。それぞれの症状によって、手術結果は異なりますのでご了承ください。
小耳症手術による合併症
一過性の顔面神経麻痺 浅側頭動・静脈の血行不良による植皮の生着不良 感染 移植軟骨の露出 気胸 術後肺炎 縫合不全 ハゲ 床ずれ その他
上記のような合併症が生じた場合は、症状に応じて対処致します。場合によっては再手術を行う可能性もあります。
